DC24V Weighing Scale Indicator Module AO 0~20mA For Transmitting

DC24V Weighing Scale Indicator Module AO 0~20mA For Transmitting

Product Details:

Place of Origin: China
Brand Name: SUPMETER
Certification: CE
Model Number: BST106-M60S[L]

Payment & Shipping Terms:

Minimum Order Quantity: 10pcs
Price: negotiate
Packaging Details: carton box
Delivery Time: 5-15 working days
Payment Terms: T/T
Supply Ability: 5000pcs/month
Get Best Price Contact Now

Detail Information

Power: DC24V Weight Display Range: -9,999~+99,999
Scale Capacity: Setting Range 1~99,999 Scale Division: Optional 1, 2, 5, 10, 20, 50, 100, 200, 500
Display Resolution: 1/50,000 Decimal Point: Optional 0, 0.0, 0.00, 0.000, 0.0000
High Light:

DC24V Weighing Scale Indicator

,

Weighing Scale Indicator Module

,

20mA Weighing Scale Indicator

Product Description

DC24V Weighing Scale Indicator Module AO 0~20mA For Transmitting

Super High Accuracy Weighing Module For Transmitting With AO (0~20mA)



Product Description:



Product Name
Weighing / Force Measuring Control Module
Application
Weight/Force Display, Peak Value Detection / Display Holding,
Auto Weight-checking, Setpoint DO Output, AO/Digit Transmission
Function
Auto-locking, Key-locking, Key-unlocking, Digital Setting&Calibration and I/O Testing functions available
Package
Caron Box



BST106-M60S[L] is a Guide Rail Type weighing module. It is with 24-bit High-precision and high-speed ∑-△A/D conversion module with 1/1,000,000 internal resolution and max. sampling frequency 1600Hz.



DC24V Weighing Scale Indicator Module AO 0~20mA For Transmitting 0







Installation:





BST106-M60S[L] is guide rail type installation

Outline Size W×H×D[mm]:  71.5×115.6×57.9
Guide Rail Groove Size W×D[mm]: 35×1.6



DC24V Weighing Scale Indicator Module AO 0~20mA For Transmitting 1



Terminal:



1. 3 Optional&definable normally open switch inputs [DI];

2. 3 Optional&definable normally open transistor switch outputs [DO]: DC24V, 250mA;
3. 1 Optional&definable current signal output [AO: 0~20mA], Non-linearity: 0.05%FS;
4. 1 Optional&definable voltage signal output [VO: 0~10V], Non-linearity: 0.05%FS;
5. COM1: RS232;
6. COM2: Optional RS485;
7. COM3: Optional CANBUS


 DC24V Weighing Scale Indicator Module AO 0~20mA For Transmitting 2
